CIDAN RAPIDO electrical guillotine shear

The CIDAN RAPIDO electrical guillotine shear is a robustly built machine that cuts all sheet thicknesses within its working range without any adjustments. This results in a durable and sturdy guillotine shear that also enhances your efficiency. It is environmentally friendly, consumes little energy, and operates quietly. The RAPIDO electrical guillotine shear comes well-equipped even in its standard configuration, making it a highly cost-effective machine.

CIDAN RAPIDO electrical guillotine shear

Key advantages

Strong and user friendly with a wide working range without blade gap adjustment

Fast with up to 35 cuts per minute

Well-equipped as standard – motorized backgauge, pneumatic sheet support, CutLink NC-control

Capacity

The CIDAN RAPIDO electrical guillotine shear is a robustly built machine that cuts all sheet thicknesses within its working range without any adjustments.

Working length

1350 – 4100

Cuts per minute

35

Steel thickness (400 N/mm2)

3,5 – 1,5

CutLink control system

RAPIDO comes standard with a CutLink control system that controls following:

  • 750 mm or 1000 mm motorized backgauge, in single or program mode.
  • Pneumatic sheet support
  • Parts counter
  • Cutting mode – single cut or continuous cut
  • Pneumatic controlled Holddownbeam (Optional)

750 or 1000 mm motorized backgauge

Fast and accurate NC- controlled motorized backgauge with T-belt and ball screw spindles.

Sheet support with front delivery

plåtupphållare i övre läget på en rapido gradsax mot vit bakgrund
Sheet support in the upper position.

The pneumatic sheet support is supporting the material during the cutting cycle. This ensures a maximum backgauge precision and prevent dog ears at the cut pieces.  After the cut, the sheet support delivers the sheet to the front of the shear.

This is a great advantage when cutting large sheets or sensitive materials like copper and zinc.

plåtupphållare i nedre läget i en rapido gradsax mot vit bakgrund
Sheet support in the lower position with front delivery.

Hold down beam with LED cutting line light

The hold down beam positioned just 32 mm from the cutting line, minimizing waste.

The beam also serves as finger protection, preventing fingers from reaching the knives.

The hold down beam has an opening at the top, providing a clear view of the LED illuminated lower shear blades. This is very helpful when cutting along marked lines.

More about hold down beam

RAPIDO table

RAPIDO has milled grooves in the table every tenth millimeter and fixed angle stops with millimeter scales on both sides.

LED-illuminated cutting line

The sheet holder has laser-cut sight windows at the top, providing a clear view of the illuminated section at the shear blades. This is very helpful when cutting along scribed lines.

bordsförlängare till rapido maskingradsax för större plåtar

Extendable table extension

An extendable table extension can be pulled out 800 mm from the cutting line, facilitating the handling of large sheets.

Moveable material wagon

The moveable material wagon is offered as an alternative to fixed return plate for return to sender option. Easily move cut material to another workstation with this option. Plus, it can be picked up with a forklift.

plåtupphållare med leverans till baksidan på en maskingradsax mot vit bakgrund

Sheet support with rear delivery

This option means that cut pieces are delivered on rollers to the back of the machine – the backgauge is 1000 mm and equipped with a fixed return plate for narrower pieces.

The rear side of the machine is covered with mechanical side fences and light guard, for easy access to the cut pieces.

Optional – Extra rails with rollers for pneumatic sheet support (rear of the machine), up to 16 rails for RAPIDO 32.

Only available for RAPIDO 32.

maskingradsax med pneumatisk plåttillhållare mot vit bakgrund

Pneumatic controlled hold down beam

Advantage when cutting soft and sensitive materials.

Squaring arms

RAPIDO can be equipped with squaring arms both with or without T-groove and tilting stop.

Discover the smart planning tool for sheet metal profiles

Efficient sheet metal processing begins and ends with nuEvolution from nuIT – the smart planning tool that revolutionizes your entire manufacturing process. Combine nuEvolution with the impressive power and agility of CIDAN’s machines for perfect oversight, great results, shorter lead times, and increased profitability. All you need is a tablet or laptop and your finger.

göteneds maskingradsax för klippning av plåt mot vit bakgrund

Technical specifications

ModelRAPIDO 13RAPIDO 26RAPIDO 32RAPIDO 41
Working length mm1350260032004100
Speed cuts/min35353535
Weight kg14001950 2100 2500
Steel13,5 mm2,5 mm2,5 mm1,5 mm
Stainless steel22,0 mm1,6 mm1,6 mm0,6 mm
Aluminum35,0 mm3,7 mm3,7 mm2,2 mm
Tensile strength 1400 N/mm22600 N/mm23200 N/mm2
